Description
130w Laser Cutter that can help you customise and individualize your business offerings!
- PLS- 1325 is a 130w Laser Cutter that can cut all sorts of materials including metal (220w Laser Cutter) and acrylics with ease, leaving you a beautiful polished finished edge.
- The 1300 mm x 2500 mm working area is ideal for large cutting jobs.
- Our 130W Laser Tube comes with a two-year warranty. It is easy and cost effective to replace. No re-gassing and no hefty costs in replacement tubes.
Easy to Use
The PLS Laser System has been developed with keeping ease of use in mind. Plugged in via USB cable the unit has a basic controller on the machine to move the machine to the location required (if working with an off-cut). All our PLS Laser systems have an auto-focus feature, ensuring that you are at the right height all the time.
The automated air assist automatically opens and closes the air valve so you do not have to flick a switch.
With the 220w Laser System easily switch between oxygen and air.
Specifications:
- 2 x Exhaust fans
- Chiller included
- Mini Blower
| MACHINE SIZE | ||
| W | D | H |
| 220 cm | 330 cm | 170 cm |
| CRATE SIZE | ||
| W | D | H |
| 240 cm | 3500 cm | 200 cm |
| WEIGHT | |
| 1600 Kg |
| Model | PLS1325 | PLS1325 |
| Laser power | 220W | 130W |
| Transmission type | Belt | Belt |
| MOTORS | Stepper Motor | Stepper Motor |
| Laser Head | CO2 or Metal-Cutting | CO2 or Non Metal-Cutting |
| WORK AREA | 1300 X 2500 mm | 1300 X 2500 mm |
| Cut speed | ≤300 mm/s | ≤300 mm/s |
| Positional Accuracy | ≤0.25 mm | ≤0.25 mm |
| Minimum line width | 0.2 mm | 0.2 mm |
| COMMUNICATION | USB connection | USB connection |
| Temp control | circulating cooling water via CW6000 Chiller | circulating cooling water via CW5200 Chiller |
| Cooling water temp | 15℃～30℃ | 15℃～30℃ |
| Environment temperature | 5℃～30℃ | 5℃～30℃ |
| Power supply | Single phase 220V/50Hz/3.5kW | Single phase 220V/50Hz/3.5kW |
